| Cab |
Cab |
| Front Axle |
MFWD |
| Transmission |
IVT |
| Guidance-ready |
Yes |
| Rear PTO |
540/1000 |
| Rear Tires |
Duals |
| Tire Width |
Narrow |
| Performance Package |
| AutoPowr Infinitely Variable Transmission (IVT) 42 km/h (26 mph) |
| One 10 in. CommandCenter Display with GreenStar 3 2630 Display |
| 4600 Processor |
| Premium CommandView III Cab with ActiveSeat |
| Premium Radio Package with XM Radio |
| Right-hand Reverser Linear-Type Transmission Controls |
| John Deere PowerTech 9.0 L (549 cu. in.) 6 Cylinder Tier 4/Stage V Compliant Diesel Engine |
| 321 L/min (85 gpm) Dual Hydraulic Pump |
| Five Premium Rear Remote SCVs with Electrohydraulic (EH) Controls, Premium Couplers, and High Pressure Relief Levers |
| 45 mm (1-3/4 in.) 1,000 rpm (20-spline) capable of 35 mm (1-3/8 in.) 540 rpm (6-spline) / 1,000 rpm (21-spline) PTO |
| 8,391 kg (18,500 lb) capacity 3-Point Hitch (Cat 3/3N) with Sway Blocks and Quik-Coupler |
| Category 4 adjustable Swinging Drawbar with 50 mm (2 in.) Pin with heavy duty support |
| 120 mm (4.72 in.) diameter by 3010 mm (118.5 in.) length with Double Taper Wheel Hubs |
| 380/90R54 152A8 R1W Radial in Dual Wheel Configuration |
| Firestone Brand Only |
| 1500 Series MFWD with hydraulic differential lock and Group 48 Rear Tires |
| 380/80R38 142A8 R1W Radial in Dual Wheel Configuration - Eight Position |
| Premium Lighting |
| Fenders, Pivoting Front - 480 mm (18.9 in.) Wide |
| Fenders, Rear Extensions 2.55 m (100 in.) Width |
| Ethernet Switch |
| Outside Mirrors - Power Telescoping, Heated, Electrically Adjustable Right-hand and Left-hand |
| Radar, Dual Beam Sensor |
| Antenna Mount and Wiring for Business Band (2-Way) Radio |
| Foot Operated Speed Control |
| Cold Weather Start Kit |
| Auxiliary Hydraulic Connections - 3/4 in. |
| Weight, front support with twenty-two suitcase weights |
| One Pair 625 kg (1378 lb) |
| One Pair 72 kg (159 lb) Starter Weights and Three Pair 205 kg (452 lb) Weights for Outer Rear Dual |
| Guidance Display |
Yes |
| 4600 with V2 Processor & Automation 4.0 |
